| Categories | 4G Dash Cams |
|---|---|
| Certification: | CE (EU Electromagnetic Compatibility & Safety), FCC (North America RF Safety), RoHS (Global Environmental Protection) |
| Viewing Angle: | Diagonal D 125° |
| Model Number: | G2 |
| Online users: | 4 users watching online simultaneously |
| Price: | US$36 |
| Packaging Details: | Color box |
| Image Sensor: | 4MP 1/3 16:9 CMOS sensor |
| Supply Ability: | 10000 |
| Memory: | 1Gbit |
| Payment Terms: | T/T |
| Operating system: | Linux |
| Delivery Time: | 30-40 days |
| Brand Name: | ODM/OEM |
| Name: | 4G DashCam |
| MOQ: | 1000 |
| Processor: | Hisilicon CV610 Cortex-A7 1T computing power |
| Company Info. |
| Shenzhen Vancen Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Specification:
| system | operating system | linux |
| Number of online users | 4 users watching online simultaneously | |
| APP | Overseas: HotKam | |
| collection | processor | Hisilicon CV610 Cortex-A7 1T computing power |
| Memory | 1Gbit | |
| Image Sensor | 4MP 1/3 16:9 CMOS sensor | |
| Viewing Angle | Diagonal D 125° | |
| Collision Sensing | Gsensor three-axis accelerometer, collision gravity sensor | |
| video | Compression Standards | H.264 /MJPEF/JPEG |
| Proactive | Main stream: 2560X1440P/30fps Preview sub-stream: 1280X720P/25fps 2G4P D125° 17 heads | |
| Rear camera | Main stream: 1920X1080P/25fps Preview sub-stream: 1280X720P/25fps AHD/2.5mm AV headphone jack Pull the camera back, the extension cable is 5.5 meters long | |
| Audio | enter | Built-in -38dB microphone |
| Sampling frequency/bit width | 16KHz/16bit | |
| Compression standard/bit rate | G711A | |
| Alarm video | Collision Alarm | When the vehicle is hit/vibrated, an alarm event is pushed to the cloud, and the mobile phone APP receives the collision message |
| Human Detection | Human detection algorithm, parking sentry mode | |
| Network | 4G (Asia Pacific) Network European Version | FDD:B1/B3/B5/B8 |
| TDD:B34/B38/B39/B40/B41 | ||
| External SIM card slot Nano 12.3mm x 8.8mm x 0.7mm | ||
| Position | GPS | Beidou/GPS dual-mode one-click car search, electronic fence, track playback; domestic Amap; overseas Google Maps |
| Button | Reset button | Long press to restore factory settings |
| Power button | Long press to turn off / short press to lock the video of interest (10 seconds) | |
| Storage | Storage function | Support T-Flash card (up to 256GB) |
| Cloud Storage | 1 day of free recurring cloud storage | |
| Working Mode | Driving mode | Vehicle start detection driving mode, high frame rate 30FPS image quality, driving sensitivity setting |
| Parking monitoring | Vehicle parking monitoring, multiple monitoring modes to choose from: sleep collision recording, intelligent full-time recording, time-lapse recording | |
| Physical indicators | Alarm detection | Collision Alarm |
| power supply | DC12V±5%@Type-C interface | |
| Work Environment | Working temperature: -10～70℃, working humidity <90% |
1. Real-time location query: check real-time vehicle status and
report a current location.
2. Regular monitoring: The terminal can upload the location
information to the platform automatically after the vehicle is
fired according to the time set by the administrator.
3. In/out of the designated area alarm: Platform setting is
required to support rectangular, circular and polygonal area
alarms.
4. Route deviation alarm: Support route deviation prompt and alarm,
sectional speed limit prompt and alarm, in/out of the designated
area or route prompt and upload information, etc.
5. Video signal loss alarm: Support camera signal identification
then the terminal will automatically report fault alarm to the
platform.
6. Low voltage alarm: When the main power supply voltage of the
active safety intelligent terminal is 24V, when it is lower than
18V, A battery lower voltage alarm will occur at the terminal; the
main power supply is 12V. When it is lower than 9V, the terminal
will bottle lower voltage alarm.
7. Location antenna disconnection alarm: When the antenna is not
connected or the link is damaged, the terminal will give a voice
prompt.
The APP has a smooth experience, allowing you to quickly open live broadcasts and playback videos
Q1: Can the camera lens angle be adjusted?
The mounting bracket is adjusted, allowing you to adjust the device
angle according to your vehicle model. You can fine-tune the angle
while previewing the real-time image via the dedicated mobile app.
Q2: Why won’t the dashcam power on?
The dashcam requires a stable power supply to boot up. Please
verify that the power connection is secure (please use the original
car charger included in the package).
Check if the power cable connector is loose at the dashcam port.
If the issue persists, contact our after-sales support team for
assistance.
Q3: What should I do if the device freezes and stops recording?
Disconnect the power supply, restart the device, and check if the
function is restored.
Try replacing the SD card with a new one, or format the existing
card (compatible with CLASS 10 U1 SD cards, 8GB–256GB capacity).
If the problem remains unresolved, contact customer service
immediately.
Q4: Why can’t the mobile phone connect to the dashcam’s Wi-Fi?
A: 1. Check if the dashcam is powered on and its Wi-Fi function is
enabled (the Wi-Fi indicator light is on).
2. Ensure the mobile phone is close to the dashcam to get the Wi-Fi
3. Verify that the mobile phone has connected to the correct Wi-Fi
name of the dashcam.
4. If the connection fails repeatedly, restart both the dashcam and
the mobile phone, then try again.
Q5: Built-in battery inquiry
This dashcam model does not have a built-in lithium battery. It
cannot power on without being connected to a car charger. Please
connect the device to the vehicle’s lighter port via the included
car charger to activate it.
|
