| Categories | Standard Hose |
|---|---|
| Model Number: | ISO 18752 MatrixFlex 5K |
| Working Pressure: | 5000 PSI / 350 Bar |
| Brand Name: | DME&JDE |
| Impulse times: | Type AC – Impulse pressure 133%, Temperature 100 °C ≥ 200,000 Times; Type CC – Impulse pressure 133% (4K), Temperature 120 °C ≥ 500,000 Times |
| MOQ: | 500M (MOQ) |
| Delivery Time: | 30days |
| Fittings: | According to the following table. Certificate: MSHA & BV & GOST & IATF 16949 & ISO 9001 & ISO 14001 & ISO 45001 & DAKKS & SGS & MA & DEKRA Approved |
| Price: | US$ 1-50 |
| Internal hose: | Synthetic rubber, extruded whole without joints, of uniform thickness |
| Reinforcement: | 2 layer of high strength steel wire braid or 4 or 6 layers of steel wire spiral. |
| Temperature: | -40 °C to +120 °C (intermittent 121 °C) -40 °C to +70 °C for water based fluids 0 °C to +70 °C hot air Prolonged operation at extreme temperatures will reduce hoses life |
| Certification: | MSHA & BV & GOST & IATF 16949 & ISO 9001 & ISO 14001 & ISO 45001 & DAKKS & SGS & MA & DEKRA |
| Payment Terms: | T/T |
| Applicable Specs: | ISO 18752 1AC/2AC/4CC |
| Covering: | Anti-abrasive synthetic rubber, resistant to oils, fuels and atmospheric conditions |
| Supply Ability: | 10 (MOQ)US$ 29.9-39.9 |
| Product name: | ISO 18752 MatrixFlex 5K Constant Working Pressure Hose |
| Place of Origin: | Hengshui City, Hebei Province, China |
| Media: | Suitable for liquids (HL, HLP, HLPD, HVLP) in mineral oil and synthetic oil MatrixFlex-rices, water based emulsifiers (HFAE, HFAS, HFB) and water glycol solvents (HFC), as well as lubricants for vegetable oil and minerals. Not suitable for chlorinated carb |
| Packaging Details: | Roll Pallet Reel |
| Company Info. |
| DME&JDE FLUID CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
Applicable Specs:
■ ISO 18752 1AC/2AC/4CC

Applications:


Hydraulic Hose specification
| Part Number | Hose Size | I.D. | R.O.D. | O.D. | Operating Pressure | Burst Pressure | Bend Radius | Weight | ISO 18752 | Ferrule | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| I.D. | Dash Size | mm | inch | mm | mm | mm | bar | psi | bar | psi | mm | kgs/m | Type | DMECode |
| MatrixFlex-5K-06 | -04 | 6.4 | 1/4" | 6.1-6.9 | 11.3 | 13.2 | 350 | 5000 | 1400 | 20000 | 75 | 0.29 | 2AC | DPF2T-04 |
| MatrixFlex-5K-08 | -05 | 8.0 | 5/16" | 7.7-8.5 | 13.1 | 14.7 | 350 | 5000 | 1400 | 20000 | 85 | 0.33 | 2AC | DPF2T-05 |
| MatrixFlex-5K-10 | -06 | 9.5 | 3/8" | 9.3-10.1 | 15.3 | 17.0 | 350 | 5000 | 1400 | 20000 | 90 | 0.42 | 2AC | DPF2T-06 |
| MatrixFlex-5K-12 | -08 | 12.7 | 1/2" | 12.3-13.5 | 18.5 | 20.7 | 350 | 5000 | 1400 | 20000 | 130 | 0.55 | 2AC | DPF2T-08 |
| MatrixFlex-5K-16 | -10 | 16.0 | 5/8" | 15.5-16.7 | 23.8 | 26.8 | 350 | 5000 | 1400 | 20000 | 250 | 0.98 | 4CC | DPF2T-10 |
| MatrixFlex-5K-19 | -12 | 19.0 | 3/4" | 18.6-19.8 | 28.1 | 31.1 | 350 | 5000 | 1400 | 20000 | 300 | 1.45 | 4CC | DPF13-12 |
| MatrixFlex-5K-25 | -16 | 25.4 | 1" | 25.0-26.4 | 35.5 | 38.5 | 350 | 5000 | 1400 | 20000 | 340 | 2.20 | 4CC | DPFR13-16 |
| MatrixFlex-5K-32 | -20 | 31.8 | 1-1/4" | 31.4-33.0 | 47.2 | 50.8 | 350 | 5000 | 1400 | 20000 | 420 | 3.06 | 4CC | DPFR13-20 |
| MatrixFlex-5K-38 | -24 | 38.1 | 1-1/2" | 37.7-39.3 | 54.1 | 57.5 | 350 | 5000 | 1400 | 20000 | 560 | 3.65 | 6CC | DPFR13-24 |
| MatrixFlex-5K-51 | -32 | 50.8 | 2" | 50.4-52.0 | 67.4 | 71.4 | 350 | 5000 | 1400 | 20000 | 640 | 4.85 | 6CC | DPFR13-32 |
Marking / Layline (Printing, Ink)


Quality Control

Certificate

Related Product

FAQ
1. Q: What is your sample policy?
A: Free samples available if we have ready part in stock, shipping
cost is on buyer's side.
2. Q: How do you guarantee your quality and what after-sale service
do you have?
A: Our factory follow the quality standard in every produce
process. Any quality problem within 12 months after purchase, we
are responsible for it.
3. Q: How do you ensure the quality?
A: We have strict QC process:
1). For raw material;
2). During the half of production;
3). Final QC before shipment
More details please review production details.
4. Q: What is your terms of price?
A: EXW, FOB, CFR, CIF, DDU.
5. Q : How do you make our business long-term and good
relationship?
A: Build Trust: Trust is the foundation of any long-term
relationship. To establish trust, we need to be transparent in our
dealings with customers and provide consistent and reliable
services.
Listen to Customers: Listen carefully to customers' feedback,
understand their needs, and customize solutions according to their
requirements.
Communicate: Maintain regular and open communication with
customers, keeping them informed about updates, new products, and
services.
Reward Loyalty: We value our loyal customers and reward their
business with discounts, special offers, and personalized services.
Provide Excellent Customer Service: We ensure our customer service
is top-notch, responding promptly to inquiries and complaints, and
going above and beyond to provide exceptional service that exceeds
customers' expectations.
6. Q: What certificates do you have?
A: Each hose we produce has obtained corresponding certificates,
especially ISO and ABS system certificates, which is the
recognition of our production capacity.
7. Q: Is it possible to visit your factory?
A: We warmly welcome you to visit our factory at any of your
convenient time.
|
