High Strength Carbon Steel Cable Mesh – For Facade Cladding

High strength carbon steel cable mesh is a cost‑effective, high‑tensile mesh system specifically designed for building facades, curtain walls, and exterior cladding applications. Made from high‑quality carbon steel wire ropes, this mesh offers excellent strength‑to‑weight ratio, good formability, and significant cost savings compared to stainless steel alternatives. When properly coated ( PVDF coated), it provides reliable corrosion resistance for exterior architectural use.

Key Features

Specification Parameters

Basic Specifications

Applications – Facade Cladding

High strength carbon steel cable mesh is designed for exterior and interior architectural cladding:

Technical Principles

Weave Construction (Ferrule Type):
Warp and weft wire ropes interlace in an over‑under plain weave pattern. Each intersection is permanently locked by a pressed steel ferrule, creating uniform diamond openings with high dimensional stability and smooth, post‑free surfaces for architectural cladding.

Wire Rope Construction:
7×7 construction (1.2–2.4mm) offers 49 wires for stiff, flat panels requiring precise geometry. 7×19 (3.2–4.0mm) uses 133 wires for higher flexibility, enabling the mesh to follow curved facades and cylindrical columns.

Material Advantage:
Hot‑dip galvanized carbon steel provides a cost‑effective, high‑strength core with a 40‑80µm zinc coating (ISO 1461). It delivers 15‑25 years of corrosion resistance in normal outdoor environments without painting.

Tools and Accessories

1.D-shackle for connecting mesh edges to turnbuckles and edge cables

2.Single hole aluminum ferrule for crimping rope ends

3.Open body turnbuckle for fine tension adjustment

4.Wire rope clip for securing loop ends

5.Expansion bolt for anchoring into concrete structures

Required Tools: Stainless steel cable cutter, crimping tool, wrench set, hydraulic tensioner, tensiometer, level, tape measure, and drill.
