EcoGuard Belt Dryer

Categories Belt Dryer
Model Number: EcoGuard
Effective Belt Length: 1-15m
Installed Power: 36kw
Operating Temperature: 40-90℃
Brand Name: Yisheng
Hot Stove Power: 2.2kw
Certification: ISO9000
Rotating Speed: 890r/min
Place of Origin: Changzhou,China
Steam Consumption: 150-370kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

EcoGuard Belt Dryer

EcoGuard Belt Dryer
Applications

Belt dryer is a common continuous dryer widely used in chemical industry, food, medicine, building materials, electronics and other industries. It provides excellent drying performance for flaky, strip and granular materials with good air permeability. For filter cakes and pasty materials, they can be granulated or extruded before drying and then processed through the belt conveyor system.

Technical Parameters
ModelDW1.6-1
(Fed Table)
DW1.6-1
(Middle Table)
DW1.6-1
(Discharge Table)
DW2-1
(Fed Table)
DW2-1
(Middle Table)
DW2-1
(Discharge Table)
Belt width (m)1.61.61.6222
Drying Section Length (m)1010810108
Material Thickness (mm)≤100≤100≤100≤100≤100≤100
Temperature (°C)50-15050-15050-15050-15050-15050-150
Heat Conduction Area (m²)525398262.5656497327.5
Steam Pressure (MPa)0.2-0.80.2-0.80.2-0.80.2-0.80.2-0.80.2-0.8
Drying Time (h)0.2-1.20.2-1.20.2-1.20.2-1.20.2-1.20.2-1.2
Driver Power (kW)0.750.750.750.750.750.75
Overall Dimensions (m)12*1.81*1.912*1.81*1.910*1.81*1.912*2.4*1.9212*2.4*1.9210*2.4*1.92

Note 1: Connect the feeding table, intermediate table and discharging table of the mesh belt dryer with uniform specifications in the above table in series to ensure the production process requirements of vegetable dehydration and drying. Significantly improve the quality and effectively ensure the quality of products.

Note 2: The height of equipment does not include the height of fans and air ducts.

Structure Overview
Three series-connected vegetable dehydration and drying production lines showing the belt dryer structure
The image shows three series-connected vegetable dehydration and drying production lines. When used in vegetable dehydration and drying production, two or more units are generally used in series to obtain better products.
