1. The project profile:
Domestic microcomputer control electronic universal testing machine started in the early 90 s, in order to improve the skill level of the enterprise products, the company has introduced foreign advanced technology, make the company's product technical level onto a new stage.

ASTM D628 ISO 527 Universal Tensile Testing Machine Professional Analysis Machine

2. Use areas:
The products are widely used in metal, non-metallic materials, mechanical properties such as pressure and bending shear test.With a wide variety of affix, can also be used for material and components of mechanical properties test.In the specimen deformation is large, fast test of rope, belt, silk, rubber, plastics, and other areas of the material test, also have a very broad application prospects.Suitable for quality supervision, teaching, scientific research, aerospace, steel, metallurgy, automobile, construction materials, and other areas of the test.

ASTM D628 ISO 527 Universal Tensile Testing Machine Professional Analysis Machine

3. According to the standard:
Meet the national standard GB/T228.1-2010 "metallic materials tensile testing at", GB/T7314-2005 "metal compression test method" requirement, in line with the GB, ISO, ASTM, DIN, and other standard data processing.Can accord with the requirement of users and provide standard.

ASTM D628 ISO 527 Universal Tensile Testing Machine Professional Analysis Machine

4. The key description:
Host: this machine adopts double space gantry structure, stretching, space on the space under compression and bending.Beam lifting.Transmission part adopts circular arc tooth synchronous belt, screw pair drive, smooth transmission, low noise.Specially designed synchronous cog belt machine driven by gear system and precision ball screw pair of moving beam movement, achieve no clearance transmission.
2. Supported by:
Standard configuration: wedge stogether tensile, compression supported by a set of each.
3. The electrical control system:
(1) adopting ac servo systems and servo motor, the performance is stable, reliable, with over-current, over-voltage, overspeed, overload protection device, etc.
(2) with overload, over-current, over-voltage and displacement fluctuation limit and emergency stop protection function.
(3) the embedded controller, which guarantees the machine can realize the control of beam displacement and other parameters, which can realize constant displacement.
(4) at the end of the test, can be manually or automatically return to test the initial position at a high speed.
(5) to achieve the real physical zero, gain adjustment and test force measurement of automatic gear shifting, zero, calibration and inventory, and without any simulation adjustment link, highly integrated control circuit.
(6) electric control circuit with reference to international standards, in line with national testing machine electrical standards, strong anti-interference ability, can guarantee the stability of the controller, the experimental data accuracy.
(7) has a network interface, data transmission and storage, can be printed out and network transfer printing, can be connected to the enterprise internal LAN or Internet network.

ASTM D628 ISO 527 Universal Tensile Testing Machine Professional Analysis Machine

5. Specification

ASTM D628 ISO 527 Universal Tensile Testing Machine Professional Analysis Machine

6, control parameters:
1. Stress control speed range: 0.005 ~ 5% FS/s
2. Stress control precision, speed rate < 0.05% FS/s, for the value of plus or minus 2%, a rate of 0.05% or more the FS/s, for the value of plus or minus 0.5%.
3. The strain speed control range: 0.005 ~ 5% FS/s
4. The strain rate of control precision: rate < 0.05% FS/s, for the value of plus or minus 2%, a rate of 0.05% or more the FS/s, for the value of plus or minus 0.5%
5. The displacement control rate range: 0.005~ 300 mm/min
6. The displacement control rate of accuracy: for set value plus or minus 0.2%
7. Constant stress, constant strain, constant displacement control range: 0.5% ~ 100% FS
8. Constant stress, constant strain, constant displacement control accuracy: value 10% FS, or for the set value of plus or minus 0.5%, value < 10% FS, for the value of plus or minus 1%
