4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA

The 4CH PMFA polarization-maintaining fiber array uses PM1310 Corning polarization-maintaining fiber, with a channel spacing of 127μm, a polishing angle of A15°, and is equipped with FC/APC connectors and 0.9mm red loose tubes.

• 4-channel polarization-maintaining fiber array design
• 127μm high-precision channel spacing
• A15° angled polishing structure
• Insertion loss IL≤0.3dB
• Extinction ratio ER≥18dB, measured up to 25dB
• Uses PM1310 Corning polarization-maintaining fiber
• FC/APC connector, slow axis alignment key
• V-groove size 10*1*1.5mm, compact structure

• Silicon photonics chip coupling
• Polarization-maintaining optical module and optical device packaging
• Coherent communication systems
• Fiber optic sensing systems
• Polarization-sensitive optical testing systems
• Laser, modulator, and integrated optical path coupling
• High-precision multi-channel optical coupling components
