D09 300 MHz ~ 6 GHz UAV RF Detection System High-precision Direction Finding Advanced Detection & Identification

D09 UAV RF Detection System: Passive Signal Locating & Identification Solution
High-Accuracy Direction Finding with Wide-Range Signal Detection
Designed for reliable signal detection and direction finding, the D09 system is a passive RF device engineered to identify UAV-related signals across a broad frequency range. It provides precise signal source direction data, enabling users to quickly assess potential signals without active transmission, ensuring non-intrusive operation for various security-focused environments.

Key Features


  • Passive RF signal detection, no active interference

    • 360° omnidirectional coverage for full-area awareness

    • High-precision direction finding with ≤3° RMS accuracy

    • Decodes major UAV protocols including DJI O2/O3

    • Supports Remote ID signal recognition

    • Provides key UAV data: SN, position, speed, altitude

    • IP66-rated for outdoor use in harsh conditions

    • Low power consumption for continuous operation

    • Fast response time under 2 seconds

Technical Specifications

ParameterDetails
Frequency Range300 MHz ~ 6 GHz
Spectrum Detection Range≥5 km
DJI O2/O3 Decoding Range≥2 km
Remote ID Detection Range≥1 km
Direction Finding Accuracy≤3° (RMS, open low-interference environment)
Coverage360° Omnidirectional
Response Time≤2 s
IP RatingIP66
Operating Temperature-40℃ ~ +55℃
Power Consumption≤100 W
Power Input220V ±10%, 50Hz ±5%
InterfacesRJ45 & Aviation Connectors
Weight≤25 kg
Dimensions≤595 mm × 575 mm


Picture image








Frequently Asked Questions
  1. Q: Is the D09 system suitable for permanent outdoor installation?
    A: Yes, with an IP66 rating and a wide operating temperature range of -40℃ to +55℃, the system is built for long-term outdoor use in various climates.
    Q: How does the passive design benefit my setup?
    A: The passive operation means the system does not emit any RF signals, so it won’t interfere with other communication or navigation equipment at your site.
    Q: What data can I get about detected signals?
    A: The system provides key details including UAV serial number, position, speed, altitude, and pilot-related information where supported by the signal.
    Q: What is the maximum range for detecting different signal types?
    A: The D09 offers a spectrum detection range of ≥5 km, protocol decoding for DJI O2/O3 up to ≥2 km, and Remote ID detection up to ≥1 km, depending on environmental conditions.
    Q: Can the system be used in border protection scenarios?
    A: Yes, the long-range detection and high-precision direction finding make the D09 suitable for use in border zones, helping to identify and locate UAV signals effectively.
