7000A Primary Current Injection Test Set Temperature Rise Test System

General Information

SXWA Series High Current Temperature Rise Test System is suitable for current load test and temperature rise test on various circuit breakers, switch gears, CT/PT and others electric equipments. SXWA Primary Current Injection Test Set is widely used in power division and industry mining enterprises.

Features
  1. Could be designed to separate or compact structure according to the volume and weight.
  2. High stability of current rising.
  3. Wide range of load changing.
  4. Auto transformer is adjustable.
  5. Reliable and easy to operate.
Specifications
  • Input voltage: 220V or 380V or at customized.
  • Current output adjustable smoothly. Precision: 1.0
  • To display primary current, secondary current test value, easy for CT/PT turns ratio test.
  • The current action time could be measured and locked.(option)
  • For temperature rise (30mins~24 hours), to be customized according to long working duration.(option)
  • Three phase current injection.(option)
  • Both AC/DC dual purpose current injection.(option)
Input VoltageAC380 Three-phase four-wire AC380
Rated Frequency50 Hz
Total System Power189kW
Total System Current287A
System Power FactorCosφ=0.8
Oil-immersed Induction RegulatorDry Uplift
Rated capacitance63kVARated capacitance63kVA
Output Voltage0-430VOutput Voltage10V
Output Current0-166AOutput Current0-6300A
Waveform Distortion≤3%Rated Input Voltage380V
Starting Voltage≤1%Load Loss<4%
Short-circuit Resistance≤7%Rated Input Current166A
