Pepperl+Fuchs NBB2-8GM30-E2 | M8 Inductive Sensor, 2mm Flush, PNP NO, 2m Cable

Pepperl+Fuchs NBB2-8GM30-E2 | M8 Inductive Sensor, 2mm Flush, PNP NO, 2m Cable
Pepperl+Fuchs NBB2-8GM30-E2 inductive proximity switch. M8×1 brass housing, 2mm flush range, PNP NO, 10-30V DC, 2m fixed PVC cable, IP67, -25 to +70°C.

Product Overview

The Pepperl+Fuchs NBB2-8GM30-E2​ is a flush-mountable inductive proximity sensor​ from the NBB (Narrow Body Barrel) M8 series, designed for non-contact detection of ferrous metal targets in space-constrained machine areas. It features an M8×1 nickel-plated brass threaded housing, 2 mm nominal sensing range (Sn) when flush-mounted, PNP Normally Open (NO) output, and a 2 m fixed PVC cable. Powered by 10–30 V DC, it is widely used for cylinder position feedback, part-presence verification, and index sensing on compact automation equipment.

Technical Specifications (Electrical & Performance)

Parameter
Specification
Order Number
NBB2-8GM30-E2
Series
Pepperl+Fuchs M8 Inductive Proximity (NBB Series)
Nominal Sensing Range (Sn)
2 mm​ (Flush Mountable — no reduction factor in metal)
Safe Operating Distance (Sa)
0 … 1.62 mm
Output Type
PNP, Normally Open (NO)
Supply Voltage
10 … 30 V DC
Max. Switching Current
200 mA (DC-13)
Voltage Drop (at Rated I)
≤ 2 V
Switching Frequency
≤ 3000 Hz
Hysteresis
≤ 10 % of Sn
Repeat Accuracy
≤ 2 % of Sn

Technical Specifications (Mechanical & Environmental)

Parameter
Specification
Housing Thread / Size
M8 × 1​ (Cylindrical)
Overall Length
~30 mm (unsheathed — "30" in model = 30 mm active length typical for M8)
Active Face Material
PBT (Polybutylene Terephthalate)
Housing Material
Nickel-plated Brass (Shielded)
Connection
2 m Fixed PVC Cable​ (Brown: +V, Blue: 0V, Black: Output — 3-wire)
Protection Rating
IP67​ (EN 60529)
Operating Temperature
-25 … +70 °C
Short-Circuit / Reverse Protection
Yes (Integrated)
Standards
EN 60947-5-2, IEC 60947-5-6 (NAMUR-compatible wiring), CE, cULus

Key Features

  • Flush Mount in Metal:​ 2 mm range maintained even when installed flush in a metal bracket (∅8.2 mm hole) — no reduction factor, simplifying cutout design.
  • High Switching Frequency:​ 3 kHz allows detection of fast-moving parts on high-speed conveyors or rotary indexing tables.
  • Fixed 2m Cable:​ Pre-wired with oil-resistant PVC cable — no separate M8 connector needed; suitable for direct home-run to terminal block or junction box.
  • Rugged Brass Housing:​ Nickel-plated brass body resists mechanical impact and provides the shielding needed for flush-mount operation.

Applications

  • Cylinder Position Feedback:​ Detecting extended/retracted position of small pneumatic cylinders via a metal target on the rod or tie-rod.
  • Part Presence in Nest:​ Verifying a stamped or machined part is correctly seated in a fixture before clamping.
  • Index / Registration Mark:​ Sensing a ferrous tab on a rotating dial or cam for homing/sequence start.
  • Tight-Space Automation:​ Any application where an M12 or M18 sensor would be too large.

Note: For NPN output​ of the same M8 2mm flush sensor with cable, see NBN2-8GM30-E2. For M12 connector version (instead of cable)​ see NBB2-8GM40-E0 (M12 4-pin plug). The 3-wire brown/blue/black cable coloring follows IEC 60947-5-6 standard — observe PNP truth table: sensor sees metal → Black = HIGH (≈ supply voltage); no target → Black = LOW (0 V).
