Product Overview

Our cross roller bearings are purpose-built for high-precision rotary transmission scenarios. Featuring an integrated inner/outer ring structure with rollers arranged orthogonally, they deliver exceptional multi-directional load capacity and ultra-high rotational rigidity within an extremely compact footprint. As a core matching component for harmonic reducers and industrial robot joints, they guarantee stable, precise and long-lasting rotary motion for demanding automation systems.

Key Features

1. Ultra-high Rigidity & Multi-directional Load Capacity

Cylindrical rollers are arranged crosswise at 90° to each other, enabling a single bearing to carry radial, axial and tilting moment loads simultaneously. Its rigidity is 3–5 times higher than standard thin-section ball bearings, perfectly meeting the heavy-load and anti-overturning requirements of robot joint shafts and harmonic reducer output ends.

2. Superior Rotational Accuracy

Precision-ground raceways and strict tolerance control deliver extremely low radial and axial runout, with minimal backlash. Available in P4 / P2 accuracy grades, it ensures repeatable positioning accuracy and smooth transmission, matching the high-precision performance of strain wave harmonic gear systems.

3. Compact & Lightweight Design

Ultra-thin cross-section profile and one-piece ring structure significantly reduce installation space and overall weight. This space-saving feature is ideal for miniaturized robot arms, compact harmonic reducer housings and end-of-arm tooling where envelope size is critical.

4. Long Service Life & Low Maintenance

Manufactured from high-purity bearing steel with advanced heat treatment, and pre-lubricated with high-performance grease. It provides smooth, low-noise operation with extended maintenance intervals, suitable for 24/7 continuous operation in industrial automation environments.

5. Full Compatibility & Customization

Complete standard size range is available, directly interchangeable with mainstream global cross roller bearing brands. Custom dimensions, preload levels and lubrication specifications can be provided to match your specific harmonic reducer and robotic joint integration design.

Typical Applications

• Industrial robot joints, rotary axes and waist joints
• Harmonic drive / strain wave gear reducers
• Precision rotary tables and indexing drives
• Semiconductor manufacturing and testing equipment
• Medical robotics and precision surgical instruments
• CNC machine tools and optical inspection devices

Quality Assurance

Every cross roller bearing undergoes 100% dimensional and accuracy inspection before delivery. Strict process control throughout grinding, assembly and testing ensures consistent performance under long-term heavy-duty conditions. We also provide professional technical support for bearing selection, preload calculation and mounting guidance for harmonic reducer and robot OEM projects.
