| Categories | ArmaFlex Foam Rubber |
|---|---|
| Min. Service Temperature: | -50 °C |
| Transport Package: | Cartons |
| Supply Ability: | Subject to order quantity and specifications |
| Density: | 45 kg/m³ |
| Type: | Flexible Elastomeric Foam Insulation |
| Thermalconductivity: | 0.034 W/m·K |
| Material: | Closed-cell elastomeric foam |
| Certification: | CE，EN 14304，ISO 9001 |
| Max. Service Temperature: | +105 °C |
| Specification: | ID 32* Tkn 40mm, Length 2m/pc |
| MOQ: | 1 carton |
| Payment Terms: | T/T |
| Water Vapour Diffusion: | 10,000 |
| Fire Performance: | Class 0 |
| Performance: | Insulating Rubber Slab |
| Fireresistance: | Self-extinguishing |
| Model NO.: | COB-40*032 |
| Watervaporpermeability: | 0.1 perm-inch |
| Place of Origin: | China |
| Temperaturerange: | -50°C to +110°C |
| Uvresistance: | Good (with protective coating) |
| Feature: | Heat-resistant, Insulating, Cold-resistant |
| Flexibility: | High |
| Application: | HVAC, refrigeration, plumbing insulation |
| Color: | Black |
| Thermal Conductivity: | 0.039 |
| Moistureresistance: | Excellent |
| Productname: | ArmaFlex |
| Trademark: | armacell |
| Environmentalcompliance: | Contains no CFCs, HCFCs or formaldehyde |
| Brand Name: | ArmaFlex |
| Delivery Time: | 15–20 days |
| Raw Materials: | Foam Rubber |
| Installation: | Easy to cut and install |
| Packaging Details: | Cartons / PE Bags |
| Surface Spread of Flame: | Class 1 |
| Company Info. |
| Myreal Energy Saving (Shanghai) Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
ArmaFlex Class 0 is a flexible insulation material that reliably
protects against water vapour ingress due to its closed-cell
structure. No additional water vapour barrier is required.
| Property | Value /Assessment | Standard / Test Method | |||||
| Temperature Range | |||||||
| Service Temperature | Max. service temperature | + 105ºC | + 85ºC if sheet or tape is glued to the object with its whole surface. | When the service temperature is under -200ºC, please contact our technical department | |||
| Min. service temperature | - 50 ºC | ||||||
| Thermal Conductivity | |||||||
| θm | -20 | +/- 0 | +40 | [ ºC ] | GB/T 10294, GB/T 10296 DIN52612, DIN52613 | ||
| λ ≤ | 0.032 | 0.034 | 0.039 | [ W/(m·k) ] | |||
| Water Vapour Diffusion Resistance | |||||||
| Water vapour diffusion resistance factor | μ > 10,000 | GB/T 17146 DIN52615 | |||||
| Water vapour permeability | ≤ 1.96 x 10-11g/(m·s·Pa) | ||||||
| Fire Performance & Approvals | |||||||
| Surface spred of flame | Class 1 | BS 476 Part 7: 1997 | |||||
| Fire performance according to building regulations | Class 0 | BS 476 Part 6: 1989 UK Building Regulation | |||||
| Burning Behaviour of Building materials and products | Class B1 | GB 8624-2012 | |||||
| Flammability | V-0, FM Approved | UL 94, FM 4924 | |||||
| Practical fire behaviour | Does not generate flaming droplets | ||||||
| Others | Registered by the Fire Services Department of Hong Kong for the
entire range of thickness. Product conforms to the requirements for building products under the Fire Safety and Shelter Department, Singapore. | ||||||
Paper Carton or plastic bags
|
