| Categories | DCI-BOX Transmission System |
|---|---|
| Description: | Supports 2 pluggable QSFP28 100G modules; Supports 1 pluggable QSFP+ 40G modules; Supports 10 pluggable SFP+ 10G modules |
| Function: | Line-side Protection Function |
| Company Info. |
| Shenzhen iseelink Communication Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Function | Description |
|---|---|
| Occupied Slots | 1/2 slots,shown in name 2/4/6/8 slot |
| Client-side Interface | Supports 2 pluggable QSFP28 100G modules Supports 1 pluggable QSFP+ 40G modules Supports 10 pluggable SFP+ 10G modules |
| Line-side Interface | Supports 1 pluggable 200G CFP2 DCO coherent module |
| Service Type | 10GE/OTU2/STM-64/10GE WAN/40GE/100GE/100GE FlexE (Unware mode)/OTU4 |
| Service Mapping Path | 2*100G client to 1*200G line mode: . 100G<-> ODU4<-> ODUC2<-> OTUC2 . OTU4<-> ODU4<-> ODUC2<-> OTUC 1*100G + 10*10G client to 1*200G line mode: . 100G<-> ODU4<-> ODUC2<-> OTUC2 . OTU4<-> ODU4<-> ODUC2<-> OTUC2 . 10G <->ODU2<->ODU4<-> ODUC2<-> OTUC2 . STM64 <-> ODU2 <-> ODU4<-> ODUC2<-> OTUC2 . OTU2 <-> ODU2<-> ODU4<-> ODUC2<-> OTUC2 1*40G + 10*10G client to 1*200G line mode: . 40G<-> ODU3<-> ODU4<->ODUC2<-> OTUC2 . 10G <->ODU2<->ODU4<-> ODUC2<-> OTUC2 . STM64 <-> ODU2 <-> ODU4<-> ODUC2<-> OTUC2 . OTU2 <-> ODU2<-> ODU4<-> ODUC2<-> OTUC2 |
| Line-side Modulation Format | 200G: 16QAM / QPSK |
| Line-side Protection Function | When switching over with the optical protection card, the switchover must be completed within 50ms. |
| Local Fault | Supports downstream insertion of Local Fault from the client side in case of Ethernet input loss or WDM side failure. Supports transparent transmission of Local Fault and Remote Fault. |
DCI5800 is an industry-leading innovative DCI OTN transmission platform launched by ISEELINK. DCI5800 has the characteristics of small size, large capacity service access, long distance transmission, Web GUI simple and convenient operation and management, reliable operation and energy saving and emission reduction, which effectively meets the needs of long-distance and large bandwidth user data center interconnection transmission. The DCI5800 features a modular design that enables both optical-electrical decoupling for cost reduction and integrated management within the same chassis. With SDN capabilities, it creates an intelligent and open network architecture. The system supports the YANG model interface based on the NetConf/YANG protocol, while also offering multiple management methods including Web GUI, CLI, NetConf,and SNMP for streamlined operations.
DCI5800 is an industry-leading innovative DCI OTN transmission platform launched by ISEELINK. DCI5800 has the characteristics of small size, large capacity service access, long distance transmission, Web GUI simple and convenient operation and management, reliable operation and energy saving and emission reduction, which effectively meets the needs of long-distance and large bandwidth user data center interconnection transmission. The DCI5800 features a modular design that enables both optical-electrical decoupling for cost reduction and integrated management within the same chassis. With SDN capabilities, it creates an intelligent and open network architecture. The system supports the YANG model interface based on the NetConf/YANG protocol, while also offering multiple management methods including Web GUI, CLI, NetConf,and SNMP for streamlined operations.
The DCI3100 integrated wavelength division equipment is developed by ISEELINK for data center interconnection (DCI) scenarios. It has the outstanding characteristics of large capacity, small size, low energy consumption and high cost performance.Housed in standard 1U chassis, this device supports max 1.6T (16*100G) capacity and can be smoothly expanded to 3.2T capacity through device stacking.Adopting high-density optoelectronic integration technology, OSP3100 avoids complex fiber jumper connections with its unique switch-like design and brings ultimate user experience by its extremely simple installation.
The passive MUX device for signal splitting operates independently of the sub-frame chassis and can be installed in a standard 19-inch data cabinet, with a height of 1U.
The passive MUX device for signal splitting operates independently of the sub-frame chassis and can be installed in a standard 19-inch data cabinet, with a height of 1U.
The Optica Linel Amplifier Module delivers a versatile, low-noise solution for erbium-doped fiber amplifiers (EDFA). This compact module operates with constant gain (Automatic Gain Control, AGC) and constant output power (Automatic Power Control, APC), featuring a highly integrated design. The large-format module supports dual amplifiers with two independent gain units, the card occupies only 1/4 standard slot capacity.
The Optical Pre Amplifier Module delivers a versatile, low-noise solution for erbium-doped fiber amplifiers (EDFA). This compact module operates with constant gain (Automatic Gain Control, AGC) and constant output power (Automatic Power Control, APC), featuring a highly integrated design. The large-format module supports dual amplifiers with two independent gain units, the card occupies only 1/4 standard slot capacity.
The Optical Boost Amplifier Module delivers a versatile, low-noise solution for erbium-doped fiber amplifiers (EDFA). This compact module operates with constant gain (Automatic Gain Control, AGC) and constant output power (Automatic Power Control, APC), featuring a highly integrated design. The large-format module supports dual amplifiers with two independent gain units, the card occupies only 1/4 standard slot capacity.
400G Transponder Card
800G Tmux Card
400G Transponder Card
400G Transponder Card
200G Muxponder Card
4U Chassis Ethernet Interface Card
Power Card
U Chassis Ethernet Interface Card
2U/4U Chassis FAN Card
2U/4U Chassis NMU Card
  | ISEELINK DCI5800 Product Specifications | PDF - 5.53 MB - Updated on Wednesday, March 25, 2026 |  |
|
