Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C

Categories Laboratory Testing Instrument
Brand Name: ZL
Model Number: ZL-1304
Certification: CE,ISO
Place of Origin: China
MOQ: 1 set
Price: Negotiable
Payment Terms: L/C, T/T, Western Union
Supply Ability: 60 Sets
Delivery Time: 5-8 work days
Packaging Details: Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C is packaged within wooden case.
Product name: Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C
Rotation speed: 5RPM, 10 RPM, 20 RPM, and 50 RPM
Temperature controlling range: 25 °C~200 °C
Temperature controlling accuracy: ±0.1 °C
Sample cylinder: 20 ml
Power supply: AC 220V±10%, 50 Hz
Relative humidity: ≤80%
Key words: Brookfield Viscometer
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C

Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C
Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter 25 °C~200 °C
Product Summary
This instrument is designed to determine the absolute viscosity of Newtonian liquids and apparent viscosity of Non-Newtonian liquids. It incorporates advanced mechanical design technologies and manufacturing techniques, utilizing microcomputer technology for temperature control, data collection, and processing.
The device features a background light, ultra-bright LCD display and is equipped with a micro-printer for data output. Test data can be displayed in real-time on the LCD or printed via the integrated printer. Additionally, the instrument can connect to a computer through the RS232 communication port.
Characterized by high measurement sensitivity, reliable data, operational convenience, and aesthetic design, this viscosity meter is widely used for determining viscosity in applications including asphalt, hot melt adhesive, paraffin, high polymers, and various fluids.
Technical Specifications
SpecificationDetails
Measurement Range100 mPa·s~200,000 mPa·s (With No.30 spindle: up to 4×10⁵ mPa·s)
SpindlesNo.21, 27, 28, 29 (4 pieces total, No.30 optional)
Rotation Speed5 RPM, 10 RPM, 20 RPM, 50 RPM
Measurement Error±2% (F·S); ±3% (F·S) with No.30 spindle
Temperature Control Range25 °C~200 °C
Temperature Control Accuracy±0.1 °C
Sample Cylinder20 ml
Power SupplyAC 220V±10%, 50 Hz
Ambient Temperature5 °C~35 °C
Relative Humidity≤80%
Note: When controlling temperature near ambient temperature, ensure ambient temperature is 5 °C lower than controlling temperature using air conditioning.
Product Image
Microcomputer Technologies NDJ-1C Brookfield Viscosity Meter
