| Categories | Explosion Proof Chain Hoist |
|---|---|
| Brand Name: | JCYC, OEM |
| Model Number: | GTB |
| Certification: | CE, ISO |
| Place of Origin: | China |
| MOQ: | 1 piece |
| Price: | 599 USD |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 5000 per month |
| Delivery Time: | around 12 workdays |
| Packaging Details: | Standard Export Package |
| Product name: | Pneumatic Balance Hoist |
| Warranty: | 1 Year |
| Power source: | Pneumatic |
| Usage: | Construction Hoist |
| Sling type: | Wire Rope |
| Capacity: | 320kg |
| Lifting height: | 2.8m |
| Lifting speed: | 20-60 m/min |
| Company Info. |
| Chongqing Shanyan Crane Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
A pneumatic balance hoist is an air-powered assisted lifting device. It uses compressed air as the power source and balances the load’s weight with the air pressure inside the cylinder through a transmission mechanism, enabling smooth lifting and lowering of heavy objects with minimal operator effort.
High lifting and lowering speed
The lifting and descending speed is typically 2–6 times faster than that of electric hoists.
“Floating” function for precise positioning
Allows easy and accurate load positioning, making fine adjustments
effortless.
Extremely high duty cycle
Designed for continuous 24-hour operation without overheating.
Safer air-powered operation
Uses compressed air as the power source, ensuring spark-free operation and higher safety, especially in hazardous environments.
Smooth and stepless speed control
Driven by a screw transmission system, providing smooth,
vibration-free lifting and lowering with infinitely variable speed control.
| Items | Unit | Specifications | ||||||
| Capacity | kg | 0-60 | 100 | 160 | 220 | 320 | ||
| SWL | m | 1.4 | 1.8 | 2.3 | 1.9.1 | 1 | ||
| Number of Wire Rope | pc | 1 | 1 | 1 | 1 | 1 | ||
| Working Medium | Compressed Air | |||||||
| Working Pressure | mpa | 0.63 | 0.63 | 0.63 | 0.63 | 0.63 | ||
| Air Consumption | M3/min | 0.18 | 0.21 | 0.21 | 0.25 | 0.3 | ||
| Hose Fitting Thread | in | PT 3/8 | PT 3/8 | PT 3/8 | PT 3/8 | PT 3/8 | ||
| Hose Dia. | mm | 10 | 10 | 12 | 12 | 12 | ||
| N.W | kg | 21 | 27 | 47 | 52 | 65 | ||
| Speed Range | Rated Load Speed | UP | m/min | 60 | 35 | 25 | 20 | 15 |
| Speed Range | No load Speed | Down | m/min | 21 | 23 | 25 | 27 | 28 |
|
