Product Overview
For those who demand sleek lines, bold contrasts, and instant
spatial expansion, this 20ft Expandable Container House is the
ultimate architectural answer. This minimalist foldable home
embraces a striking monochrome aesthetic, featuring pristine white
horizontal siding sharply accented by heavy, matte-black window and
door frames. It strips away unnecessary ornamentation to deliver a
pure, ultra-modern look that feels right at home in a trendy Buenos
Aires suburb as a backyard office, a creative tech park pod, or an
upscale beachfront studio. This high-contrast design not only looks
premium but also maximizes natural light through its wide,
black-framed sliding glass doors.
As a flagship product designed and manufactured by Global House
(Suzhou) Co., Ltd., this unit represents the true pinnacle of
contemporary modular housing. We prioritize smart engineering,
utilizing a high-strength galvanized steel skeleton that ensures
the expandable container house remains completely rigid and secure,
whether folded for transport or fully expanded for daily use. The
minimalist exterior conceals highly effective thermal and acoustic
insulation, while the premium black-framed windows feature advanced
sealing technology to protect against heavy rains and high winds
typical of sudden South American weather shifts.
The brilliance of this modern 20ft expandable container house lies
in its transformative nature. Catering to the demand for
quick-build commercial and residential extensions, this structure
drastically reduces your project timeline. It is transported
efficiently in a tightly closed, standard 20ft shape. Once it is
lowered onto your prepared foundation, the real innovation is
revealed. The side walls glide outward effortlessly, unlocking a
massive, expansive interior that is up to three times larger than
its original shipping size. This rapid, fold-out expansion allows
you to instantly generate a spacious, open-concept creative
workspace, a chic tech pod, or a sophisticated minimalist living
area without the headaches of traditional construction.
Specifications & Loading Capacity
| Type | Extended Size L*W*H (mm) | Folded Size L*W*H (mm) | Area | 40HQ Loading | Shipping Weight |
|---|
| 10FT Model | 2950 * 6480 * 2480 | 2950 * 2200 * 2480 | 20 m² | 4 SETS | ~1.8 - 2.0 Tons |
| 20FT Model | 5900 * 6480 * 2480 | 5900 * 2200 * 2480 | 38.2 m² | 2 SETS | 3.4 Tons |
| 30FT Model | 9000 * 6480 * 2480 | 9000 * 2200 * 2480 | 58.3 m² | 1 SET | ~4.5 Tons |
| 40FT Model | 11800 * 6480 * 2480 | 11800 * 2200 * 2480 | 76.4 m² | 1 SET | 5.4 Tons |
Detailed Material Specifications
- Main Steel Frame: Q235 Hot-dip galvanized steel, 2.5mm - 3.0mm thickness, with 6mm
corner head liner plates for maximum structural safety.
- Wall Panels: External wall: 75mm EPS sandwich panel standard (Upgradable to
Rock Wool for premium fire resistance). Internal partition: 50mm
EPS sandwich panel.
- Roof System: External top: 0.35mm corrugated color steel sheet. Insulation:
50mm EPS sandwich panel. Internal ceiling: 200-type aesthetic
ceiling board.
- Flooring: Subfloor: 18mm fireproof magnesite board (moisture-proof &
insect-resistant). Surface: 2.0mm wear-resistant PVC floor leather
(Upgradable to 4.0mm SPC flooring).
- Doors & Windows (Optional Upgrade): PVC casement windows (with anti-insect screens) + Aluminum
security door.
Available Upgrades: Broken bridge aluminum entrance doors (double glass), KFC doors,
aluminum alloy sliding doors, broken bridge aluminum windows,
plastic steel sliding windows, ceiling-to-floor glass windows, etc.
Color Customization: Wall panel colors: White, Red Wooden, Dark Gray. Frame colors:
White, Black, Dark Gray. Optional: 16mm metal carved board as
exterior wall decoration.
Target Applications
Project Camps (construction dormitories, site canteens, modular
restrooms); Office Spaces (mobile office units, field command
centers, temporary meeting rooms); Emergency Housing (post-disaster
resettlement, refugee shelters, affordable pods); Utility Buildings
(security booths, temporary clinics, mobile convenience stores).
How It Works (4-Step Deployment)
1. Unloading: Lift the folded unit onto leveled, hardened ground or simple
concrete piers.
2. Unfolding Wings: Release the safety latches, lift the two roof sections in
sequence, and then lower the floor sections.
3. Fixing Walls: Push the folded side walls outward to a vertical position and
install the corner connectors.
4. Sealing: Apply prefabricated sealing strips and high-quality structural
adhesive at joints to ensure a weather-tight finish.
Frequently Asked Questions
Q1: Are you a manufacturing factory or a trading company? Where is
your factory located?
A: We are a direct manufacturing factory. Our plant is located in
Zhenze Town, Wujiang County, Suzhou City, Jiangsu Province, China.
We welcome global clients and third-party inspection agencies to
visit us at any time.
Q2: What is the lifespan of this container house? Is it stable
under extreme weather?
A: Under standard conditions, the galvanized steel frame has a
lifespan of 15 to 20 years. Structurally, it is extremely safe;
when properly anchored to a foundation, it can resist winds up to
200km/h and withstand up to a magnitude-9 earthquake outside.
Q3: Can the electrical and plumbing systems meet my local country's
strict compliance standards?
A: Yes. We regularly export to regions with strict compliance
requirements. We can pre-install electrical wiring, sockets, and
plumbing systems that fully meet specific local certifications
(such as CE for Europe or AU/NZS for Australia and New Zealand) to
ensure fast council approval.
Q4: How long does it take to build? Do I need professional
engineers?
A: No professional technicians are needed. We provide comprehensive
installation videos and manuals. Generally, 2 workers can master
the operation and complete a standard room setup within about 3
hours using basic lifting equipment.
Q5: What is your standard delivery time?
A: Delivery time depends on order quantities and customization. For
standard sizes and configurations, delivery preparation generally
takes 15 to 20 days after receiving the deposit (with standard
scaling varying within 5-15 days depending on exact queue lines).
Q6: What should I provide to get a customized layout or design
scheme?
A: It's very easy! If you have a sketch drawing or reference photo,
you can send it to us directly. If not, simply notify us of your
requirements, such as the total area, target usage, room/sanitary
layout, and material preferences, and our design team will provide
a detailed scheme and quotation.
