Belt Drive Continuous Disc Stack Centrifuges Machine For Virgin Coconut Oil

Categories Disc Stack Centrifuges
Brand Name: Peony
Model Number: PDSC204-SD
Certification: ISO
Place of Origin: China
MOQ: 1
Payment Terms: TT, LC
Supply Ability: 100sets per month
Delivery Time: 45days
Packaging Details: Standard export packing
Driving Mode: Belt Drive
Product Name: Disc Centrifuge Virgin Coconut Oil
RPM: 11200rpm
Outlet pressure of clear liquid: ≤0.2MPa
Pressure of feeding: ≤0.2MPa
Starting Mode: Friction Startup
Machine type: Centrifugal Machine for Coconut Oil
Automatic degree: Fully automatic
Discharge means: Self Cleaning
Separation: Solid-liquid or Solid-liquid-liquid separation
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    Belt Drive Continuous Disc Stack Centrifuges Machine For Virgin Coconut Oil

    Popular Disc Stack Centrifuges Machine Continuous Disc Centrifuge Virgin Coconut Oil


    Structure Features


    The material of drum doby, drum cover and valve is high strength stainless steel, the Moc of other parts are all high quality, anti-corrosion SS304, the separator shell employ SS304.


    Drive structure support use SKF bearing, by employing optimal design to reduce the height of the drum’s center of gravity. It can effectively lower the vibrational level of the whole separator, improve the reliability of the equipment and increase the stability of the separator.
    In the dismounting and maintenance, the parts of drum can be hoisted integrally, thus make the dismounting of main lock ring more convenient, saving both time and labor, easy to install the drum.
    The separator runs supercurrent, it will send warning signals and be stoped if the machine overload, to make the separator runs safely.
    The separator has a less vibration and more stability through price dynamic balance of the drum.
    The separator adopts separation factor technology. It can separate product that is hard to separate, meanwhile, the machine has light volume and use the small volume to get big capacity and high separation efficiency.
    The separator adopts advance belt drive, improving the reliability and maintainability of the separator, and decreasing cost of spare parts.
    Dimensions
    Main Technical Specification

    Capacity

    L/h

    < 1000

    Working diameter of bowl

    mm

    Φ230

    RPM

    rpm

    11200

    Discharge type


    Self-cleaning (PLC control)

    Vibration

    mm/s

    ≤2.8

    Noise

    dB(A)

    ≤85

    Starting Mode


    Frequency Startup

    Driving Mode


    Belt Drive

    N.W.

    Kgs

    371

    Dimension

    (L*W*H)mm

    930×750×1050

    Motor

    Power

    Kw

    7.5

    Cost analysis

    Compared selling price and maintenance cost with ,
    Westfalia and other domestic manufacturers
    Single Value Analysis

    1. Peony adopts SKF bearing , which is consistent with Alfa, Westfalia.
    2. Alfa and Westfalia only provide clients with the bearing and the gear in the overhaul package(need to buy separately) while Peony has more sufficient attachment supply.

    3. Peony never reduce the amount of spare parts and tools for users buying many sets of the same model machine. (unless the customer put forward in specially).
    4. Regular spare parts are all in stock in Peony’s company.


    More picture



    Guarantee


    Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time. We are committed to reward you with a better quality in return for our interest in and faith toward. We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
